| 1 |
24510211AB
|
VERTICAL BELT OUTER COVER
|
€
44.60
|
|
|
| 2 |
24510221AB
|
OUTER CENTRAL COVER
|
€
28.56
|
|
|
| 3 |
24510201AB
|
HORIZONTAL BELT OUTER COVER
|
€
44.60
|
|
|
| 4 |
24510411A
|
VERTICAL BELT INNER COVER
|
€
94.71
|
|
|
| 5 |
24510421A
|
HORIZONTAL BELT INNER COVER
|
€
94.35
|
|
|
| 6 |
85310021A
|
WASHER, SPRING
|
€
0.96
|
|
|
| 7 |
77110518B
|
BOLT, SOCKET HEAD M6X25
|
€
0.96
|
|
|
| 8 |
77150658B
|
SCREW TCEI M6X16
|
€
0.96
|
|
|
| 9 |
77110471A
|
SCREW
|
€
0.96
|
|
|
| 10 |
14710142A
|
TIMING LAY SHAFT
|
€
166.75
|
|
|
| 11 |
88210031A
|
SNAP RING
|
€
2.02
|
|
|
| 12 |
68010131A
|
KEY, WOODRUFF 4X5X10
|
€
0.96
|
|
|
| 13 |
17120202B
|
TIMING GEARS PAIR
|
€
446.11
|
|
|
| 14 |
85110131A
|
WASHER, LOCK
|
€
0.96
|
|
|
| 15 |
75011601A
|
NUT M14X1X7
|
€
3.08
|
|
|
| 16 |
68010131A
|
KEY, WOODRUFF 4X5X10
|
€
0.96
|
|
|
| 17 |
71311661A
|
SPACER
|
€
21.10
|
|
|
| 18 |
25510041A
|
PULLEY, TIMING
|
€
71.49
|
|
|
| 19 |
85610022A
|
BELT ROLLER SEPARATING WASHER SP. 2
|
€
5.52
|
|
|
| 20 |
85211731A
|
WASHER 15.2X24X1
|
€
0.96
|
|
|
| 21 |
70350062A
|
ELASTIC-STOP RING NUT
|
€
7.65
|
|
|
| 22 |
73710101b
|
TIMING DRIVE TOOTHED BELT
|
€
78.40
|
|
|
| 23 |
45110042A
|
FIXED TENSIONER ROLLER PIN
|
€
37.02
|
|
|
| 24 |
70250015A
|
BEARING
|
€
10.53
|
|
|
| 25 |
45110101A
|
FIXED TENSIONER BUSH
|
€
32.09
|
|
|
| 26 |
735033380
|
CIRCLIP
|
€
0.96
|
|
|
| 27 |
735001747
|
SEEGER RING 17 DIN 471
|
€
0.96
|
|
|
| 28 |
45110331A
|
TENSIONER ECCENTRIC
|
€
26.71
|
|
|
| 29 |
45110012A
|
MOVABLE TENSIONER ROLLER PIN
|
€
36.10
|
|
|
| 30 |
74940081A
|
NUT
|
€
2.02
|
|
|
| 31 |
45110341A
|
MOVABLE TENSIONER ROLLER BUSH
|
€
30.12
|
|
|
| 32 |
70250222A
|
BEARING
|
€
26.09
|
|
|
| 33 |
735033450
|
CIRCLIP
|
€
0.50
|
|
|
| 34 |
735002054
|
SPRING RING
|
€
0.96
|
|
|
