| 1 |
77941992A
|
SCREW
|
1 |
€
0.78
|
|
|
| 2 |
7791A751B
|
SCREW, SPECIAL
|
2 |
€
1.22
|
|
|
| 3 |
48612261A
|
DAMPER, SOUND ARRESTER
|
3 |
€
10.15
|
|
|
| 4 |
82718913A
|
SHEET ACOUSTIC DAMPER
|
4 |
€
22.84
|
|
|
| 5 |
77550200CC
|
SCREW
|
5 |
€
0.50
|
|
|
| 6 |
85611551A
|
WASHER
|
6 |
€
1.00
|
|
|
| 7 |
78010921A
|
PLUG
|
7 |
€
2.53
|
|
|
| 8 |
22032083A
|
GASKET, ALUMINIUM 28X22.5X1
|
8 |
€
0.55
|
|
|
| 9 |
76412121A
|
VIBRATION DAMPER PAD
|
9 |
€
1.26
|
|
|
| 10 |
7791B491A
|
SCREW, SPECIAL
|
10 |
€
2.21
|
|
|
| 11 |
88640331A
|
O-RING 17.96X2.62
|
11 |
€
1.52
|
|
|
| 12 |
53940302A
|
SWITCH ASSY, OIL PRESSURE
|
12 |
€
40.70
|
|
|
| 13 |
55241321C
|
SENSOR, TIMING & RPM
|
13 |
€
57.38
|
|
|
| 14 |
85211951A
|
GASKET TH.2
|
14 |
€
0.50
|
|
|
| 15 |
85310031A
|
WASHER, SPRING
|
15 |
€
0.50
|
|
|
| 16 |
77253304C
|
SCREW
|
16 |
€
0.50
|
|
|
| 17 |
88650321A
|
O-RING
|
17 |
€
1.23
|
|
|
| 18 |
24311611BH
|
CLUTCH COVER
|
18 |
€
570.71
|
|
|
| 19 |
89320121A
|
PLUG ASSY
|
19 |
€
6.87
|
|
|
| 20 |
88640891A
|
O-RING 18.64X3.53
|
20 |
€
7.31
|
|
|
| 21 |
77942002A
|
SCREW
|
21 |
€
1.00
|
|
|
| 22 |
88642721A
|
O-RING
|
22 |
€
0.50
|
|
|
| 23 |
66810591A
|
FILLER
|
23 |
€
7.52
|
|
|
| 24 |
93042231A
|
SEAL RING
|
24 |
€
8.40
|
|
|
| 25 |
88450291A
|
SNAP RING
|
25 |
€
0.50
|
|
|
| 26 |
85212721A
|
THRUST WASHER
|
26 |
€
0.75
|
|
|
| 27 |
93041521A
|
SEAL RING
|
27 |
€
11.85
|
|
|
| 28 |
78110121AA
|
SCREW, SPECIAL
|
28 |
€
10.39
|
|
|
| 29 |
85250241A
|
COPPER GASKET 11.9X8.2X2
|
29 |
€
0.50
|
|
|
| 30 |
87712481A
|
OIL PRESSURE LINE
|
30 |
€
27.19
|
|
|
| 31 |
76440581A
|
RUBBER PAD
|
31 |
€
1.46
|
|
|
| 32 |
43312502C
|
TRANSFER "SHELL ULTRA
|
32 |
€
1.93
|
|
|
| 33 |
48612293A
|
DAMPER, SOUND ARRESTER MIDDLE
|
33 |
€
5.62
|
|
|
| 34 |
48612271A
|
DAMPER, SOUND ARRESTER WATER PUMP
|
34 |
€
8.79
|
|
|
| 35 |
82718944A
|
LAMIERA FONOASSORBENTE CENTRALE
|
35 |
€
8.00
|
|
|
| 36 |
82718923A
|
SHEET ACOUSTIC DAMPER WATER PUMP
|
36 |
€
17.13
|
|
|
| 37 |
82718933A
|
PERIMETER SOUNDDEADENING METAL SHEET
|
37 |
€
20.54
|
|
|
| 38 |
48612281A
|
PERIMETER SOUNDDEADENING PANEL
|
38 |
€
5.14
|
|
|
| 39 |
8291J241AA
|
CONNECTOR HOLDER
|
39 |
€
4.56
|
|
|
| 40 |
82718991A
|
SHEET ACOUSTIC DAMPER
|
40 |
€
11.41
|
|
|
| 41 |
48612551A
|
DAMPER, SOUND ARRESTER
|
41 |
€
3.43
|
|
|
