| 1 |
79910491A
|
SPRING, RETURN
|
€
3.90
|
|
|
| 2 |
85210532A
|
WASHER 8.2X20X1
|
€
0.90
|
|
|
| 3 |
77910391A
|
SCREW M8X21.5
|
€
1.90
|
|
|
| 4 |
45520181A
|
GEAR FIXING CLICK ASSEMBLY
|
€
7.46
|
|
|
| 5 |
85211111A
|
GASKET TH.0.5
|
€
0.90
|
|
|
| 5 |
85211971A
|
GASKET 2 MM
|
€
0.90
|
|
|
| 5 |
050403085
|
GASKET 1.5 MM
|
€
0.90
|
|
|
| 6 |
53910211A
|
SWITCH
|
€
33.63
|
|
|
| 7 |
77912031A
|
PUSH ROD HOLDER
|
€
8.62
|
|
|
| 8 |
027291090
|
GASKET 16.2X24X2
|
€
0.90
|
|
|
| 9 |
066013143
|
GEAR SELECTOR SPRING
|
€
1.90
|
|
|
| 10 |
768351134
|
BALL 11MM
|
€
0.90
|
|
|
| 11 |
067013075
|
1ST,3RD-2ND GEAR SELECTOR FORK
|
€
100.08
|
|
|
| 12 |
067013080
|
4TH,5TH GEAR SELECTOR FORK
|
€
65.07
|
|
|
| 13 |
066013070
|
AXLE, GEAR SHIFT FORK 10X116 MM
|
€
7.96
|
|
|
| 14 |
85210051A
|
THRUST WASHER 1 MM
|
€
1.90
|
|
|
| 15 |
735001542
|
CIRCLIP 15 DIN 471
|
€
0.90
|
|
|
| 16 |
88210061A
|
NEEDLE RETAINING RING
|
€
1.90
|
|
|
| 17 |
82110701A
|
SPECIAL ROLLER
|
€
1.90
|
|
|
| 18 |
18220121A
|
COMPLETE GEARBOX DRUM
|
€
138.57
|
|
|
| 19 |
85210941A
|
THRUST WASHER 45.2X49X0.9
|
€
2.90
|
|
|
| 19 |
066013060
|
THRUST WASHER 45.2X49X1.0
|
€
1.90
|
|
|
| 20 |
79912961A
|
RETURN SPRING
|
€
2.90
|
|
|
| 21 |
076592205
|
THRUST WASHER 10.5X15X0.2
|
€
0.90
|
|
|
| 22 |
88450341B
|
RING, BENZING 8MM DIN 6799
|
€
0.90
|
|
|
| 23 |
74810401A
|
NUT, FLANGE
|
€
0.90
|
|
|
| 24 |
18020261A
|
CONTROL FORK
|
€
19.25
|
|
|
| 25 |
066013165
|
GEARCHANGE LEVER PIN
|
€
8.43
|
|
|
| 26 |
82110011A
|
GEAR SELECTOR SHAFT
|
€
134.90
|
|
|
| 27 |
79915061A
|
SPRING SHIFT RETURN
|
€
3.90
|
|
|
| 28 |
77150678B
|
BOLT, SOCKET HEAD M6X20
|
€
0.90
|
|
|
| 29 |
46230038A
|
WASHER
|
€
0.50
|
|
|
| 30 |
77151238B
|
SCREW
|
€
0.90
|
|
|
| 31 |
85310021A
|
WASHER, SPRING
|
€
0.90
|
|
|
| 32 |
88110121A
|
CENTERING RING
|
€
18.36
|
|
|
| 33 |
82610091A
|
STOPPER PLATE
|
€
19.64
|
|
|
| 34 |
040029126
|
THRUST WASHER 15.5X22X0.5
|
€
1.90
|
|
|
