| 1 |
24510391A
|
VERTICAL BELT OUTER COVER
|
€
147.00
|
|
|
| 2 |
24510401A
|
OUTER CENTRAL COVER
|
€
166.84
|
|
|
| 3 |
24510381A
|
HORIZONTAL BELT OUTER COVER
|
€
120.36
|
|
|
| 4 |
24510182AB
|
VERTICAL BELT INNER COVER
|
€
39.87
|
|
|
| 5 |
24510192AB
|
HORIZONTAL BELT INNER COVER
|
€
18.44
|
|
|
| 6 |
45110211A
|
MOVABLE TENSIONER ROLLER BUSH
|
€
30.66
|
|
|
| 7 |
77110518B
|
BOLT, SOCKET HEAD M6X25
|
€
0.90
|
|
|
| 8 |
77150658B
|
SCREW TCEI M6X16
|
€
0.90
|
|
|
| 9 |
77110471A
|
SCREW
|
€
0.90
|
|
|
| 10 |
14710141A
|
LAYSHAFT TIMING
|
€
169.34
|
|
|
| 11 |
88210031A
|
SNAP RING
|
€
1.90
|
|
|
| 12 |
85310021A
|
WASHER, SPRING
|
€
0.90
|
|
|
| 13 |
17120202B
|
TIMING GEARS PAIR
|
€
420.50
|
|
|
| 14 |
85110131A
|
WASHER, LOCK
|
€
0.90
|
|
|
| 15 |
75011601A
|
NUT M14X1X7
|
€
2.90
|
|
|
| 16 |
68010131A
|
KEY, WOODRUFF 4X5X10
|
€
0.90
|
|
|
| 17 |
71311661A
|
SPACER
|
€
19.89
|
|
|
| 18 |
25510041A
|
PULLEY, TIMING
|
€
67.39
|
|
|
| 19 |
85610021A
|
THRUST WASHER 2 MM
|
€
5.20
|
|
|
| 19 |
85610491A
|
THRUST WASHER 0.3 MM
|
€
1.90
|
|
|
| 19 |
85610501A
|
THRUST WASHER 0.2 MM
|
€
1.90
|
|
|
| 20 |
85211731A
|
WASHER 15.2X24X1
|
€
0.90
|
|
|
| 21 |
70350062A
|
ELASTIC-STOP RING NUT
|
€
7.21
|
|
|
| 22 |
73710101b
|
TIMING DRIVE TOOTHED BELT
|
€
73.90
|
|
|
| 23 |
45110042A
|
FIXED TENSIONER ROLLER PIN
|
€
34.89
|
|
|
| 24 |
70250012A
|
BEARING
|
€
0.00
|
|
|
| 25 |
45110101A
|
FIXED TENSIONER BUSH
|
€
30.25
|
|
|
| 26 |
735033380
|
CIRCLIP
|
€
0.90
|
|
|
| 27 |
735001747
|
SEEGER RING 17 DIN 471
|
€
0.90
|
|
|
| 28 |
45110021A
|
ECCENTRIC TENSIONER
|
€
21.63
|
|
|
| 29 |
45110012A
|
MOVABLE TENSIONER ROLLER PIN
|
€
34.03
|
|
|
| 30 |
74940081A
|
NUT
|
€
1.90
|
|
|
| 31 |
45110071A
|
PULLEY, MOVABLE TENSIONER
|
€
23.56
|
|
|
| 32 |
68010131A
|
KEY, WOODRUFF 4X5X10
|
€
0.90
|
|
|
| 33 |
71312411A
|
SPACER 6.2X10X7
|
€
0.90
|
|
|
| 34 |
75810201A
|
FAIRLEAD
|
€
3.90
|
|
|
| 35 |
85211761A
|
WASHER
|
€
0.90
|
|
|
| 36 |
77350728B
|
SCREW
|
€
0.90
|
|
|
