| 1 |
77157528B
|
SCREW TCEIF M10X20
|
€
5.20
|
|
|
| 2 |
85611361A
|
WASHER, NYLON 11X5.2X0.5
|
€
0.96
|
|
|
| 3 |
85040821A
|
THREADED INSERT WELLNUT M5X0.8X16
|
€
2.02
|
|
|
| 4 |
48015031AW
|
UPPER HALF-FAIRING L.H. WHITE
|
€
401.47
|
|
|
| 4 |
48015031AT
|
UPPER HALF-FAIRING L.H. BLACK
|
€
482.74
|
|
|
| 4 |
48015031AA
|
UPPER HALF-FAIRING L.H. RED
|
€
401.47
|
|
|
| 5 |
43713071BG
|
STICKER 848 FOR WHITE
|
€
11.90
|
|
|
| 5 |
43713071AT
|
STICKER 848 FOR BLACK
|
€
11.17
|
|
|
| 5 |
43713071AG
|
STICKER 848 FOR RED
|
€
11.17
|
|
|
| 6 |
48012281CG
|
LOWER HALF-FAIRING L.H. GREY FOR WH FOR RED
|
€
367.12
|
|
|
| 6 |
48012281BK
|
LOWER HALF-FAIRING L.H. BLACK FOR B
|
€
367.12
|
|
|
| 6 |
48012281BG
|
LOWER HALF-FAIRING L.H. GREY FOR WH FOR WHITE
|
€
365.79
|
|
|
| 7 |
48610732A
|
INSULATING PANEL LEFT
|
€
62.76
|
|
|
| 8 |
48610742A
|
INSULATING PANEL RIGHT
|
€
62.76
|
|
|
| 9 |
48012302CG
|
LOWER HALF-FAIRING R.H. GREY FOR WH FOR RED
|
€
367.12
|
|
|
| 9 |
48012302BG
|
LOWER HALF-FAIRING R.H. GREY FOR WH FOR WHITE
|
€
365.79
|
|
|
| 9 |
48012302BK
|
LOWER HALF-FAIRING R.H. BLACK FOR B
|
€
367.12
|
|
|
| 10 |
85041091A
|
WASHER, SPRING
|
€
0.96
|
|
|
| 11 |
48015021AW
|
UPPER HALF-FAIRING R.H. WHITE
|
€
401.47
|
|
|
| 11 |
48015021AA
|
UPPER HALF-FAIRING R.H. RED
|
€
401.47
|
|
|
| 11 |
48015021AT
|
UPPER HALF-FAIRING R.H. BLACK
|
€
482.74
|
|
|
| 12 |
46012491A
|
LEFT PANEL
|
€
8.85
|
|
|
| 13 |
77214411AA
|
SCREW BLACK
|
€
3.08
|
|
|
| 14 |
85044691A
|
QUICK FASTENING
|
€
0.00
|
|
|
| 15 |
56420711AA
|
FRONT MUDGUARD ASSEMBLY RED
|
€
171.02
|
|
|
| 15 |
56420711AW
|
FRONT MUDGUARD ASSEMBLY WHITE
|
€
171.02
|
|
|
| 15 |
56420711AT
|
FRONT MUDGUARD ASSEMBLY BLACK
|
€
171.02
|
|
|
| 16 |
48410601AG
|
AIR CONVEYOR
|
€
53.11
|
|
|
| 17 |
77210893B
|
SCREW
|
€
4.14
|
|
|
| 18 |
71614011A
|
SPACER 6.2X8.5X14
|
€
2.02
|
|
|
| 19 |
75840181A
|
CLAMP WIRE 11 MM
|
€
0.96
|
|
|
| 20 |
85212181A
|
WASHER, NYLON 9X14X1
|
€
0.96
|
|
|
| 21 |
83014681A
|
BRACKET COWLING LH
|
€
22.40
|
|
|
| 22 |
77210861B
|
SCREW TBEI M5X18
|
€
2.02
|
|
|
| 23 |
77210943B
|
SCREW, SPECIAL
|
€
3.08
|
|
|
| 24 |
46012481A
|
RIGHT BULKHEAD
|
€
8.85
|
|
|
