| 1 |
59521002A
|
RIDER SEAT
|
€
175.20
|
|
|
| 2 |
86611041A
|
RUBBER PAD (BIG)
|
€
0.90
|
|
|
| 3 |
86611181A
|
RUBBER PAD (LITTLE)
|
€
10.20
|
|
|
| 4 |
85040471A
|
QUICK FASTENING M5
|
€
0.90
|
|
|
| 5 |
77210842A
|
SPECIAL SCREW
|
€
2.90
|
|
|
| 6 |
77214411AA
|
SCREW BLACK
|
€
2.90
|
|
|
| 7 |
48330822B
|
TAIL GUARD (FRONT) (BOTTOM)
|
€
8.90
|
|
|
| 8 |
86611071A
|
RUBBER PAD (REAR)
|
€
2.90
|
|
|
| 9 |
48310814A
|
VASCHETTA
|
€
9.22
|
|
|
| 10 |
24723424AA
|
COVER SEAT (RED)
|
€
189.21
|
|
|
| 10 |
24723424AQ
|
COPERCHIO SELLA (DIAMOND BLACK)
|
€
193.19
|
|
|
| 11 |
85040381A
|
QUICK FASTENING
|
€
2.90
|
|
|
| 12 |
48320751AA
|
TAIL GUARD (RED)
|
€
699.39
|
|
|
| 12 |
48320751AQ
|
CODONE (DIAMOND BLACK)
|
€
699.39
|
|
|
| 13 |
77211091C
|
SCREW
|
€
4.90
|
|
|
| 14 |
75011551A
|
NUT M22X1.5
|
€
1.90
|
|
|
| 15 |
69720252A
|
TOOL BAG
|
€
13.55
|
|
|
| 16 |
59521012A
|
PILLION RIDER SEAT
|
€
172.15
|
|
|
| 17 |
48310762A
|
TAIL GUARD (REAR) (BOTTOM)
|
€
95.32
|
|
|
| 18 |
82714821A
|
PLATE
|
€
5.40
|
|
|
| 19 |
43810811A
|
STICKER "DUCATI" (FOR RED)
|
€
8.39
|
|
|
| 19 |
43810811AT
|
DECALCOMANIA "DUCATI" (PER DIAMOND BLACK)
|
€
8.39
|
|
|
| 20 |
59810131A
|
LOCK LATCH
|
€
27.02
|
|
|
| 21 |
77914982A
|
SCREW TCPEI M6
|
€
3.90
|
|
|
| 22 |
59820611A
|
SEAT LOCK
|
€
50.83
|
|
|
| 23 |
83015641A
|
HOOK
|
€
18.25
|
|
|
| 24 |
74941118B
|
NUT, FLANGED M6X1.00
|
€
0.90
|
|
|
| 25 |
76410541A
|
RUBBER PAD
|
€
4.90
|
|
|
| 26 |
77211091A
|
SCREW TBEI M5X12
|
€
4.90
|
|
|
| 27 |
77914992A
|
SPECIAL SCREW
|
€
1.90
|
|
|
| 28 |
85044691A
|
QUICK FASTENING
|
€
2.30
|
|
|
| 29 |
91371141R
|
LIBRETTO USO E MANUTENZIONE
|
€
25.79
|
|
|
| 29 |
91371141T
|
LIBRETTO USO E MANUTENZIONE
|
€
25.79
|
|
|
| 29 |
91371141S
|
LIBRETTO USO E MANUTENZIONE
|
€
25.79
|
|
|
| 29 |
91371141V
|
LIBRETTO USO E MANUTENZIONE
|
€
25.79
|
|
|
| 30 |
48211562A
|
BODY PANEL (L.H.)
|
€
133.16
|
|
|
| 31 |
48211572A
|
BODY PANEL (R.H.)
|
€
133.16
|
|
|
| 32 |
88440251A
|
CIRCLIP
|
€
0.90
|
|
|
| 33 |
79911751A
|
SPRING
|
€
2.90
|
|
|
| 34 |
84110371A
|
RETAINER
|
€
4.90
|
|
|
| 35 |
86611082A
|
BATTERY RESTING BUFFER
|
€
2.90
|
|
|
| 36 |
77211041A
|
SCREW
|
€
2.90
|
|
|
| 37 |
70010601A
|
VIBRATION DAMPER
|
€
10.47
|
|
|
| 38 |
85540011A
|
SPRING WASHER
|
€
0.90
|
|
|
| 39 |
74850061A
|
NUT
|
€
5.56
|
|
|
| 40 |
73210171A
|
ANTI-THEFT CABLE
|
€
4.90
|
|
|
| 41 |
86610301A
|
PAD
|
€
1.90
|
|
|
