| 1 |
30120193BA
|
HORIZONTAL HEAD (2,3,6,7 INCLUDED)
|
€
1098.93
|
|
|
| 2 |
30320041C
|
EXHAUST VALVE GUIDE, BRONZE
|
€
38.29
|
|
|
| 2 |
30320041CD
|
EXHAUST VALVE GUIDE +0.09 MM
|
€
25.19
|
|
|
| 2 |
30320041CB
|
EXHAUST VALVE GUIDE +0.03 MM
|
€
38.29
|
|
|
| 2 |
30320041CC
|
EXHAUST VALVE GUIDE +0.06 MM
|
€
38.29
|
|
|
| 3 |
30310031A
|
INTAKE VALVE GUIDE, CAST IRON
|
€
38.29
|
|
|
| 3 |
30310031AD
|
GUIDE INTAKE VALVE +0.09 MM
|
€
31.46
|
|
|
| 3 |
30310031AC
|
GUIDE INTAKE VALVE +0.06 MM
|
€
38.29
|
|
|
| 3 |
30310031AB
|
GUIDE INTAKE VALVE +0.03 MM
|
€
38.29
|
|
|
| 4 |
30410052AB
|
SEAT, INLET VALVE +0.03 MM
|
€
41.26
|
|
|
| 4 |
30410052A
|
SEAT, INTAKE VALVE
|
€
19.75
|
|
|
| 4 |
30410052AC
|
SEAT, INLET VALVE +0.06 MM
|
€
41.26
|
|
|
| 5 |
30410062AC
|
SEAT, EXHAUST VALVE +0.06 MM
|
€
40.30
|
|
|
| 5 |
30410062AB
|
SEAT, EXHAUST VALVE +0.03 MM
|
€
40.30
|
|
|
| 5 |
30410062A
|
SEAT, EXHAUST VALVE
|
€
44.24
|
|
|
| 6 |
21110034A
|
EXHAUST VALVE
|
€
138.75
|
|
|
| 7 |
21010035A
|
INTAKE VALVE
|
€
119.15
|
|
|
| 8 |
076592185
|
THRUST WASHER 10.5X15X1
|
€
0.50
|
|
|
| 8 |
061992180
|
THRUST WASHER 10.5X15X0.3
|
€
0.50
|
|
|
| 8 |
076592190
|
THRUST WASHER 10.5X15X0.5
|
€
1.94
|
|
|
| 8 |
076592195
|
THRUST WASHER 10.5X15X0.1
|
€
0.70
|
|
|
| 8 |
076592205
|
THRUST WASHER 10.5X15X0.2
|
€
0.89
|
|
|
| 8 |
067092190
|
THRUST WASHER 10.5X15X2
|
€
0.50
|
|
|
| 9 |
79910613A
|
CLOSING ROCKER SPRING
|
€
7.68
|
|
|
| 10 |
066092245
|
ROCKER ARM PIN, OVERSIZED
|
€
3.30
|
|
|
| 10 |
066092240
|
ROCKER ARM PIN
|
€
29.16
|
|
|
| 11 |
78810322A
|
GASKET CYLINDER HEAD COVER
|
€
2.70
|
|
|
| 12 |
24010101AB
|
VALVE COVER
|
€
69.79
|
|
|
| 13 |
77150678B
|
BOLT, SOCKET HEAD M6X20
|
€
0.50
|
|
|
| 14 |
072792239
|
SEE TABLE
|
€
0.00
|
|
|
| 15 |
66910031A
|
HALF-RINGS
|
€
2.06
|
|
|
| 16 |
072392239
|
SEE TABLE
|
€
0.00
|
|
|
| 17 |
20810123A
|
OPENING ROCKER
|
€
181.21
|
|
|
| 18 |
20910123A
|
CLOSING ROCKER
|
€
192.48
|
|
|
| 19 |
037592210
|
SPRING
|
€
2.43
|
|
|
| 20 |
064770010
|
WASHER, THRUST
|
€
0.50
|
|
|
| 21 |
76410091A
|
SEAL VALVE STEM
|
€
5.34
|
|
|
| 22 |
76410131A
|
SEAL VALVE STEM
|
€
2.20
|
|
|
| 23 |
70010271A
|
VIBRATION DAMPER PAD
|
€
0.52
|
|
|
| 24 |
24010121BB
|
INTAKE VALVE COVER
|
€
71.70
|
|
|
| 25 |
M300160
|
CAP, RUBBER
|
€
1.07
|
|
|
| 26 |
735001747
|
SEEGER RING 17 DIN 471
|
€
0.50
|
|
|
| 27 |
71311371A
|
SPACER
|
€
0.98
|
|
|
| 28 |
88640281A
|
O-RING
|
€
1.81
|
|
|
| 29 |
78710081A
|
ALUMINIUM GASKET
|
€
0.91
|
|
|
| 30 |
70310191A
|
RING NUT
|
€
38.64
|
|
|
| 31 |
82912351A
|
HOLDER SENSOR
|
€
47.63
|
|
|
| 32 |
55240131A
|
WATER TEMPERATURE SENSOR
|
€
35.47
|
|
|
| 33 |
069191030
|
CLAMP --- Tiewrap
|
€
0.50
|
|
|
