| 1 |
30121041AA
|
COMPLETE HORIZONTAL HEAD
|
€
931.96
|
|
|
| 2 |
30310041CB
|
OVERSIZE VALVE GUIDE 0.03
|
€
30.27
|
|
|
| 2 |
30310041C
|
EXHAUST VALVE BRONZE GUIDE
|
€
30.27
|
|
|
| 2 |
30310041CD
|
OVERSIZE VALVE GUIDE 0.09
|
€
30.27
|
|
|
| 2 |
30310041CC
|
OVERSIZE VALVE GUIDE 0.06
|
€
30.27
|
|
|
| 3 |
30310031AC
|
GUIDE INTAKE VALVE +0.06 MM
|
€
38.29
|
|
|
| 3 |
30310031A
|
INTAKE VALVE GUIDE, CAST IRON
|
€
38.29
|
|
|
| 3 |
30310031AB
|
GUIDE INTAKE VALVE +0.03 MM
|
€
38.29
|
|
|
| 3 |
30310031AD
|
GUIDE INTAKE VALVE +0.09 MM
|
€
31.46
|
|
|
| 4 |
30410221AB
|
SEAT, EXHAUST VALVE +0.03 MM
|
€
84.24
|
|
|
| 4 |
30410221AC
|
SEAT, EXHAUST VALVE +0.06 MM
|
€
84.24
|
|
|
| 4 |
30410221A
|
SEAT, EXHAUST VALVE
|
€
20.19
|
|
|
| 5 |
30410211AB
|
SEAT, INLET VALVE +0.03 MM
|
€
84.24
|
|
|
| 5 |
30410211A
|
SEAT, INTAKE VALVE
|
€
16.68
|
|
|
| 5 |
30410211AC
|
SEAT, INLET VALVE +0.06 MM
|
€
32.30
|
|
|
| 6 |
21010151A
|
INTAKE VALVE
|
€
90.16
|
|
|
| 7 |
21110151A
|
EXHAUST VALVE
|
€
104.05
|
|
|
| 8 |
076592205
|
THRUST WASHER 10.5X15X0.2
|
€
0.90
|
|
|
| 8 |
061992180
|
THRUST WASHER 10.5X15X0.3
|
€
0.50
|
|
|
| 8 |
076592185
|
THRUST WASHER 10.5X15X1
|
€
0.90
|
|
|
| 8 |
067092190
|
THRUST WASHER 10.5X15X2
|
€
0.90
|
|
|
| 8 |
076592190
|
THRUST WASHER 10.5X15X0.5
|
€
2.90
|
|
|
| 9 |
79910613A
|
CLOSING ROCKER SPRING
|
€
7.68
|
|
|
| 10 |
82111151A
|
ROCKER SHAFT
|
€
10.49
|
|
|
| 11 |
78810322A
|
GASKET CYLINDER HEAD COVER
|
€
2.90
|
|
|
| 12 |
24010101AB
|
VALVE COVER
|
€
69.79
|
|
|
| 13 |
77150678B
|
BOLT, SOCKET HEAD M6X20
|
€
0.90
|
|
|
| 14 |
072792239
|
SEE TABLE
|
€
0.00
|
|
|
| 15 |
66910031A
|
HALF-RINGS
|
€
2.90
|
|
|
| 16 |
072392239
|
SEE TABLE
|
€
0.00
|
|
|
| 17 |
20810124A
|
OPENING ROCKER
|
€
178.34
|
|
|
| 18 |
20910124A
|
CLOSING ROCKER
|
€
185.56
|
|
|
| 19 |
037592210
|
SPRING
|
€
2.90
|
|
|
| 20 |
064770010
|
WASHER, THRUST
|
€
0.90
|
|
|
| 21 |
76410091A
|
SEAL VALVE STEM
|
€
5.34
|
|
|
| 22 |
76410131A
|
SEAL VALVE STEM
|
€
2.90
|
|
|
| 23 |
85250231A
|
GASKET
|
€
0.90
|
|
|
| 24 |
24010121BB
|
INTAKE VALVE COVER
|
€
71.70
|
|
|
| 25 |
77911331A
|
SCREW, SPECIAL TCEI M6X12
|
€
1.90
|
|
|
| 26 |
735001747
|
SEEGER RING 17 DIN 471
|
€
0.90
|
|
|
| 27 |
71311371A
|
SPACER
|
€
1.90
|
|
|
| 28 |
88640281A
|
O-RING
|
€
1.90
|
|
|
| 29 |
78710081A
|
ALUMINIUM GASKET
|
€
1.90
|
|
|
| 30 |
70310191A
|
RING NUT
|
€
38.64
|
|
|
| 31 |
82912351A
|
HOLDER SENSOR
|
€
47.63
|
|
|
| 32 |
55240131A
|
WATER TEMPERATURE SENSOR - imitation
|
€
35.47
|
|
|
| 33 |
67210341A
|
RUBBER CAP
|
€
2.90
|
|
|
| 34 |
M300160
|
CAP, RUBBER
|
€
1.90
|
|
|
| 35 |
70010271A
|
VIBRATION DAMPER PAD
|
€
0.90
|
|
|
