| 1 |
22520871C
|
MATCHED CRANKCASES
|
€
8833.63
|
|
|
| 2 |
11210481AE
|
HALF-BEARING (BOTTOM) (BRONW)
|
€
82.76
|
|
|
| 2 |
11210481AH
|
HALF-BEARING (BOTTOM) (BLUE/BLACK)
|
€
82.76
|
|
|
| 2 |
11210481AF
|
HALF-BEARING (BOTTOM) (BLACK)
|
€
82.76
|
|
|
| 2 |
11210481AG
|
HALF-BEARING (BOTTOM) (RED/BLACK)
|
€
82.76
|
|
|
| 3 |
11210471AH
|
HALF-BEARING (UPPER) (BLUE/BLACK)
|
€
28.78
|
|
|
| 3 |
11210471AE
|
HALF-BEARING (UPPER) (BRONW)
|
€
28.78
|
|
|
| 3 |
11210471AG
|
HALF-BEARING (UPPER) (RED/BLACK)
|
€
28.78
|
|
|
| 3 |
11210471AF
|
HALF-BEARING (UPPER) (BLACK)
|
€
25.60
|
|
|
| 4 |
76610431A
|
STUD BOLT
|
€
12.07
|
|
|
| 5 |
76610441A
|
STUD BOLT
|
€
8.16
|
|
|
| 6 |
77340301A
|
SCREW
|
€
1.26
|
|
|
| 7 |
83014491B
|
PLATE
|
€
30.91
|
|
|
| 8 |
77340031A
|
SCREW
|
€
0.98
|
|
|
| 9 |
70240721A
|
ROLLER BEARING
|
€
32.48
|
|
|
| 10 |
82713101B
|
PLATE
|
€
21.44
|
|
|
| 11 |
77340051A
|
SCREW
|
€
0.98
|
|
|
| 12 |
70250401A
|
NEEDLE BEARING
|
€
13.91
|
|
|
| 13 |
70240541A
|
BEARING
|
€
69.70
|
|
|
| 14 |
76610401A
|
STUD BOLT
|
€
8.18
|
|
|
| 15 |
76610621A
|
STUD BOLT
|
€
14.85
|
|
|
| 16 |
85250241A
|
COPPER GASKET 11.9X8.2X2
|
€
0.50
|
|
|
| 17 |
53910211B
|
NEUTRAL SWITCH ASSY
|
€
13.26
|
|
|
| 18 |
74810471A
|
NUT
|
€
2.81
|
|
|
| 19 |
74810461A
|
NUT, FLANGE M10X1
|
€
2.17
|
|
|
| 20 |
77913541A
|
THREADED PLUG M15X1
|
€
13.77
|
|
|
| 21 |
85211201A
|
ALUMINIUM GASKET
|
€
1.04
|
|
|
| 22 |
85610642A
|
WASHER, SPECIAL 10.5X21X2
|
€
0.50
|
|
|
| 23 |
71111931A
|
BUSH
|
€
4.98
|
|
|
| 24 |
88640931A
|
O-RING
|
€
0.70
|
|
|
| 25 |
13210071C
|
PISTON JET
|
€
58.75
|
|
|
| 26 |
71110922A
|
BUSH
|
€
11.38
|
|
|
| 27 |
71111641A
|
BUSH
|
€
4.58
|
|
|
| 28 |
77913601A
|
CAP
|
€
14.18
|
|
|
| 29 |
88641121A
|
O-RING
|
€
0.84
|
|
|
| 30 |
85250271A
|
WASHER
|
€
0.50
|
|
|
