| 1 |
79910491A
|
SPRING, RETURN
|
€
3.90
|
|
|
| 2 |
85210532A
|
WASHER 8.2X20X1
|
€
0.90
|
|
|
| 3 |
77910391A
|
SCREW M8X21.5
|
€
1.90
|
|
|
| 4 |
45520181A
|
GEAR FIXING CLICK ASSEMBLY
|
€
7.46
|
|
|
| 5 |
85250241A
|
COPPER GASKET 11.9X8.2X2
|
€
0.90
|
|
|
| 6 |
53910211B
|
NEUTRAL SWITCH ASSY
|
€
13.26
|
|
|
| 7 |
77912033A
|
SCREW M16X1.5
|
€
6.41
|
|
|
| 8 |
027291090
|
GASKET 16.2X24X2
|
€
0.90
|
|
|
| 9 |
066013143
|
GEAR SELECTOR SPRING
|
€
1.90
|
|
|
| 10 |
768351134
|
BALL 11MM
|
€
0.90
|
|
|
| 11 |
034013075
|
1ST,4TH-2ND,3RD GEAR SELECTOR FORK
|
€
61.74
|
|
|
| 12 |
034013080
|
5TH,6TH GEAR SELECTOR FORK
|
€
61.74
|
|
|
| 13 |
066013070
|
AXLE, GEAR SHIFT FORK 10X116 MM
|
€
7.96
|
|
|
| 14 |
85210051A
|
THRUST WASHER 1 MM
|
€
1.90
|
|
|
| 15 |
735001542
|
CIRCLIP 15 DIN 471
|
€
0.90
|
|
|
| 16 |
88210061A
|
NEEDLE RETAINING RING
|
€
1.90
|
|
|
| 17 |
82110701A
|
SPECIAL ROLLER
|
€
1.90
|
|
|
| 18 |
18220283A
|
COMPLETE GEARBOX DRUM
|
€
213.53
|
|
|
| 19 |
85210941A
|
THRUST WASHER 45.2X49X0.9
|
€
2.90
|
|
|
| 20 |
79912961A
|
RETURN SPRING
|
€
2.90
|
|
|
| 21 |
076592205
|
THRUST WASHER 10.5X15X0.2
|
€
0.90
|
|
|
| 22 |
88450341B
|
RING, BENZING 8MM DIN 6799
|
€
0.90
|
|
|
| 23 |
74810401A
|
NUT, FLANGE
|
€
0.90
|
|
|
| 24 |
18020261A
|
CONTROL FORK
|
€
19.25
|
|
|
| 25 |
066013165
|
GEARCHANGE LEVER PIN
|
€
8.43
|
|
|
| 26 |
82110011A
|
GEAR SELECTOR SHAFT
|
€
134.90
|
|
|
| 27 |
79915061A
|
SPRING SHIFT RETURN
|
€
3.90
|
|
|
| 28 |
77150670Z
|
SCREW TCEI M6X20
|
€
0.50
|
|
|
| 29 |
71319151A
|
SPACER
|
€
2.90
|
|
|
| 30 |
77151250Z
|
FSCREW
|
€
0.54
|
|
|
| 31 |
040029126
|
THRUST WASHER 15.5X22X0.5
|
€
1.90
|
|
|
| 31 |
040029125
|
THRUST WASHER 15.5X22X0.2
|
€
1.90
|
|
|
| 32 |
88110121A
|
CENTERING RING
|
€
18.36
|
|
|
| 33 |
82610291A
|
STOPPER PLATE
|
€
20.03
|
|
|
| 34 |
75810451A
|
HOLDER, WIRE
|
€
3.90
|
|
|
| 35 |
51016581A
|
CABLE NEUTRAL SWITCH
|
€
2.90
|
|
|
